Rotary Pick Fill Seal Machine

Range of Rotary Pick Fill Seal Machine

4th Gen
PFS Packing Machine

Beautiful Packaging
Upto 45 Bags/Min

Premade Pouch Packaging Machine can pack most products with a fast speed. Choosing suitable premade bags can greatly improve the appearance and ease of use for consumers.

Large Bag
PFS Packing Machine

Best for Large Packaging
Range 1-5 kgs bags
Model designed to cater the need of large bag packaging ranging 1-5 kgs, perfectily suitable for Rice-Pulses-Flour-Grain industry who need packaging solution for upto 5 kgs premade bags.

Air Suction System
PFS Packing Machine

Compact Yet Powerful
Perfect for Nuts & Dry-fruits

These types of machines are a variant of the rotary premade pouch packaging machines that include an additional air suction system to semi vacuum the product to increase the self-life.

5th Gen High Speed
PFS Packing Machine

High Performance – Higher Productivity
Upto 65 Bags/Min

Latest 5th Gen Rotary Pick Fill Seal Packaging Machines have attractive and modern design perfectly suits the production floor who requires highest performance and productivity.

Retort-Ready to eat
PFS Packing Machine

Retort Pouch Packaging
Perfect for RTE Foods

This particular PFS Machine allows manufacturers of RTE foods to conveniently pack their perishable products, safely, in a wide variety of Retort Pouch, which can then be subjected to retort for longer shelf life.

Non Wovan Bag
PFS Packing Machine

Unique and Powerful
Bulk Packaging 2-10 Kgs

These machines use a rotating turret to pick up, fill, and Stitch Premade Non-Wovan bags. Topping the best in class machine in it’s segment provide unique solution of Rice-Grain-Flour Industry.

Types of Bags Suitable for Rotary PFS Machine

Rotary Pick-Fill-Seal Packaging Machine

Rotary Pick-Fill-Seal (PFS) Packing Machine are the perfect solution for all type of premade bags irrespective of it’s shapes and sizes. These Machines streamline your operations and increase output by as much as 50 percent with premade pouch, unlike VFFS machinery that utilizes roll stock film to create bags, Our premade pouch packing machines offer something completely different.

These latest and innovative packaging machines Pick-Fill-Seal already premade custom pouches, so no rollstock is required. Moreover it can also perform online vacuum with more advance system. The end result – your packaged product looks modern, offers convenience, and differentiates itself from your competition.

Features include:

  1. Incredibly easy to operate and maintain with smart interference program.
  2. Package anything from Snacks & Confectionery, to Grains & Granular, to Paste & Liquids, to pet foods, to powders, to legal cannabis products
  3. Easy integration with different types of filling systems, infeed and outfeed conveying equipment, inspection systems to secondary packaging machines.
  4. Perfect and accurate Rapid sealing System
  5. The latest Siemens/Mitsubishi and other internationally renowned components and servo drives
  6. Durable & Waterproof stainless construction
  7. Can pack any type of Premade/Preformed Bags like Zipper, Standup, Doy Pouch, Special Shape, Flat Bottom, Gusseted, Slider, Spout, 3 Side Seal etc…

Suitable Products

  1. Liquid – Handwash, Detergent, Yellow rice wine, Soy sauce, Rice vinegar, Juice, Tomato paste, Peanut paste, Fruit paste, Chili sauce, Bean sauce, etc.
  2. Granule – Ready-Premixes, Crystal MSG, Granule medicine, Capsule, Seeds, Raw Chemistry material, Sugar, Chicken essence, Melon seed, Nuts, Pesticides, Fertilizer, Feed, etc.
  3. Powder – Ready-to-Cook Premixes, Flour, Flavoring, MSG, Milk powder, Glucose, Washing powder, Raw chemistry material, White sugar, Pesticides, Fertilizers, etc.
  4. Solid – Dry-Fruits, Namkeen, Pulses, Rice, Candy, Red dates, Oatmeal, Chocolate, Cookies, Peanut, Green soybeans, Rock candy, Pastry, Commodity, Puffed food, etc.

PFS Machine Process

  1. Giving Bag – Feed many pouches or bags in the bag magazine, our main bag magazine can move up and down, you can feed bags very easily when it moved down, and when it moved up, there are a mechanical arm with two vacuum caps will take the bag up and then transmit it to the mechanical gripper on the rotary table.
  2. Date Printing – According to the actual production and packaging needs, different types of coding machines are configured to print the date and batch number on the packaging bag.
  3. Opening Bag – While the suction cup opens the opening of the packaging bag, air is sprayed from the upper nozzle to blow open the bottom of the packaging bag, the packaging bag support plate is inserted into the opening of the packaging bag, and the packaging bag enters the next station. After inserting the bag support plate into the bag opening, the detection of whether there is a packaging bag and whether the opening of the bag is opened is completed. If there is no packaging bag or there is no opening to open the packaging bag, the next station will not feed.
  4. Filling & Consolidate 1 – According to different packaging materials, different feeders are configured at this station to complete the automatic or semi-automatic delivery of materials.
  5. Filling & Consolidate 2
  6. Buffering (or Other) – Nitrogen Dosing – Zipper Closing
  7. Heat Sealing 1 – To seal the pouch or bag mouth with a couple of heat sealing air bar, the sealing pattern you can option, net or straight lines.
  8. Heat Sealing 2 – To make the sealing stable and preventing from wrinkling with a couple of cold press, then output the finished production automatically.
